Scanning and Screening Solutions

Door Frame Metal Detector

The THS SX are one of the world’s finest walk through/door frame metal detectors and works on a superior pin point technology and unmatched discrimination features. It has a unique multi zone design which guarantees, first-rate performance to customers. Comprising of all safety features, the THS SX door frame metal detectors are truly the first choice of metal security door for professionals worldwide.

International norms (NILECJ-0601 L1-5/IP54/IEC 348/EN60950 Class1) In conformity with CE European Union Norms and produced under ISO 9001: 2000 QMS
Multi-Zone – minimum 9 real detection zones
Auto Calibration (Automatically calibrates itself up to Environmental Conditions)
Human friendly VLF technology (Certified) Green/Red bicolor traffic through LEDs
These metal detectors have light indicators at side panels and control panel
20 sensitivity levels, 5 Security levels set to International Security Standards (fixed NILECJ security levels), 246 adjustable sensitivity steps at each, applicable to all zones separately (Jailhouse Requirements Met)
Separate Zone Sensitivity Settings
SMART DETECTOR – Automatic Sensitivity Program selects the correct sensitivity for a specific weapon or a recognized test object (fast consistent calibration)
Superior Discrimination, Precise target location identification
Graphic zone display
Metal Density Display at 10-level-VU meter with green, yellow, red LEDs Environment magnetic noise level detection display on LCD Screen Adjustable audio alarm at 10 tons/level
Alarm Counter & Five Digit Separate incoming & outgoing counters (Visible/invisible) Mechanical Lock for control panel and four-digit changeable digital Pin Code Automatic Failure Display
Standard Uninterruptible Power Supply (UPS) enabling 4 hours operation without mains
Reloading the factory default settings by one-touch button Easy programming and monitoring with LCD display Relay outputs for recording CCTV, controlling turnstiles, etc on Alarms
Modem and RS232 output for SCADA remote data communication- Send Receive – Change settings by direct cable or modem over Telecom Lines by PC- Audible & Visual alarms can be monitored by PC and can be logged into Hard Disk (optional Software)
Certificate approved “Safe for wearers of pacemakers and pregnant women” — No effect to magnetic media (eg. Memory sticks, tape, proximity cards)
Easy-to-mount and assemble walk through door frame metal detector (15 minutes)

Hand-Held Metal Detectors

After many years of active service our “AD” series hand held metal detectors need no introduction. They have been operating around the clock under some of the harshest working conditions year after year.

As a result of our uncompromising standards in manufacturing and design, Adams Electronics has a continuous development program in progress. The ongoing improvement of micro-technology has allowed us to constantly upgrade our “AD” series detectors, maintaining our position at the cutting edge of modern technology.

With many thousands of these detectors in use around the world, the Adams AD Series detectors are the preferred choice of metal detector where superlative performance, durability and reliability are essential requirements.

Dimensions	Length – 11.5cm(4.5 inches), Width – 6.5cm(2.5 inches) Height – 3cm (1.25 inches)
Weight	6.4oz or 181 gms including battery
Sensitivity	Target size 0.1gms Fully automatic. No adjustment necessary.
Operating Temperature	-20oC to +65oC
Storage Temperature	-30oC to +80oC
Humidity	98%
Ingress Protection	IP64 (IEC529)
Power Consumption	Standby
Active Mode Current (no detection)	Less that 1 mA
Active Mode Current (metal detected)	6.5 mA
Battery	One 9 Volt block battery MN 1604, 6LR61 or equivalent alkaline disposable or rechargeable
Operating time, TZ-20(V)	150hours continuous (or greater) at +25C (alkaline battery) 80 hours at +25C(rechargeable battery single charge)
Operating time, TZ-20	550mA hours (Standard 9 Volt Block battery) 180 mA hours NiCad rechargeable
Battery Management System	Precision monitoring. Low voltage or defective battery is signalled by a continuous vibration (TZ-20(V) or audio tone (TZ-20) alarm signal)
Alarm Indication	Audio/visual (TZ-20) Vibration alarm (tactile) indicator (TZ-20V)
Speed of detection	Ultra fast; ‘Detect-alarm-reset’ ready for another target-0.1 second
Size of target indication	At constant sweep speed: short digital pulse=small target. Long pulse=large target
Simple single control operation	(Single switch On/Off)
Instant response to all metals	tested and approved to EEC EN5008-1 Table 1. EN50082-1 Table 1:1.1
Technology	Radiated emissions. Conforms to international standards IEG, NILEC STANDARD – 0602.02-FCC, FAA.
Medically tested and approved	No risk to personal with pacemakers

Baggage Scanners

The CX6040BI is an advanced daul-energy X-ray inspection system. CX6040BI is perfectly suitable for all security and customes applications.

World-leading image quality with high wire resolution of 38AWG
Threat Image Projection (TIP) ready X-ray system
Complying with all international safety and health standard
High reliable operating and data storage safety are guaranteed by applications of industrial computer, embedded system, and data access strategy and configurations
Modular design and constructions, combined with full built-in diagnostic facilities
Explosives and narcotics detection and alarms according to the atomic number signatures
X-ray leakage around the equipment is close to natural background level
Ergonomic keyboard and user interface design ensure the efficiency and professionals of baggage screening operating
Optimized concept of operations, centralized image identify and storage capability implemented by various network applications

General Specifications
Tunnel dimensions (in mm) (w x h)	606 X 420
Conveyer speed (in m/s)	0.20
Conveyer height (in mm)	680
Max. load (in kg)	160
Image Performance
Wire resolution	0.1mm (34AWG)0
Steel penetration (in mm)	34
Display resolution	1280 x 1024
Image Processing System
Image enhancement	Color/BW, negative, high/low penetration, organic/inorganic stripping, general enhancement, multi-absorptivity, and suspect material enhancement, etc.
Material classification	According to atomic number signatures
ROI & zoom	Steps/step less zoom, up to 32 times enlargement
Image recall	Preceding images recallable
Image store capability	Up to 50,000
Miscellaneous functions
Standard functions	Time/date display, counters, user management, system-on/X-ray-on timers, power on self-test, built-in diagnostic facilities, dual-direction scanning, system log, system standby and training, etc.
Optional functions	Explosives/narcotics detections, high-density area alert, threat image projection (TIP)
Health & safety
X-ray leakage	Less than 1µGy/h (5cm from the housing),complying with all published international standards
Film safety	Guaranteed for high speed film up to ASA/ISO1600 (33DIN)
Installation data
Dimensions (in mm) (l x w x h)	2042 x 850 x 1300
Weight (in kg)	500
Storage temperature/humidity	-40°C~ +60°C/ 5% ~ 95% (non-condensing)
Operating temperature/humidity	0°C +40°C / 5% ~ 95% (non-condensing)
Power supply	220VAC/110VAC (-15%~ +10%), 50 Hz/60 Hz ±3 Hz
Power consumption	0.6kVA
X ray generator voltage	160 kV

Under-Vehicle Scanning System

“NORKA” is a unique portable X-ray detector with a minifocus and microfocus constant-potential X-ray source. The voltage can be adjusted from 2 0 to 160kV. This allows inspecting objects made from (20-70kV is the optimal voltage for checking mail and thin objects, while 100-160kV works best for baggage and thick objects). One of the advantages of this X-ray inspection system is its ability to inspect areas of an object in fine detail using geometric magnification (up to 40 times).

The UVSS provides high resolution stitched image of the underside of the vehicles
It scans vehicles of all categories and sizes
Scans any moving vehicle (up to a speed of 30 Kmph) and produces a high quality image of its underside, in real-time
Provides a high resolution stitched image of the underside of the vehicles
Facilitates intelligent and quick comparison of the current underside image with archived one of the same vehicle.
The 3 Auxiliary cameras provide for additional view of ‘Hard-to-See’ areas, in video motion.
State – of – the –Art software for User-friendly interaction with the system.
The UVSS can be networked to centralized monitoring and database management system.
Automated classification and alert facility.
The UVSS can be seamlessly integrated with other security equipment like boom barriers, tyre killers, access control systems etc.
Efficient viewing and monitoring is possible.
The under vehicle scanner ensures quick detection of foreign items e.g. explosives, bomb etc.
One under vehicle surveillance system fits all.
Facilitates peak hour inspection without stopping any vehicle.
Very high output saves time while maintaining high standards.
The UVSS is a crucial time saver
Detection of any unusual modification shall enhance chances of detecting any disguised object.
A convenient security aid for crucial and large events such as exhibitions.
Crucial aid in post event analysis.
Provides One – stop solution for all security needs
Easier to navigate, ensure better usage of the system

Main Camera	Sensor Type	Linear Colour CCD
	Resolution	4096 Pixels
	Video Format	Camera Link
	Certifications
	Dimensions in mm	56(W), 60(H), 39.4(L)
Auxiliary And License Plate Cameras	Sensor Type	Colour Area CCD
	No. of Pixels	110 K Pixels
	Video Format	NTSC/PAL
	Resolution	480 TV Lines
	Power Supply	12 V DC
Processing Units	Processor	Pentium 4 (3GHZ)
	Ram	1 GB DDR
	Hard Disk Memory	500 GB
	PCI Slots	3 PCI Slots
Sensor Unit	Type	Inductive Loop Sensor
	Power Requirements	12 V
	Output	NPN/ PNP
Lighting Unit	Halogens / CFL	12 V DC / 55 Watt x 4 in
		62 in x 60 in x 11 in
		100 in x 72 in x 4 in

X-Ray Detector System

Control unit based on an industrial microprocessor and 12” TFT LCD with touch screen
Digital camera unit (1300×1024, 14-bit)
Interchangeable X-ray converter viewing area: 300×400 mm (standard) with converter unit support. Interchangeable
Converters are available on request: 190×250 and 410x550mm
Specially designed minifocus & microfocus X-ray digital generators
From the RAP series (constant potential with the voltage up to 300kV)
Focusing device (optional for microfocus X-ray units)
Set of connecting cables
PC mouse & keyboard (optional)
USB-flash drive (optional)
Rechargeable battery & charging device
User’s manual
Set of transport bags or transport case

General specifications

X -RAY UNIT	NORKA – 160	NORKA – 120	NORKA – 150
Operation Mode	5-25 second exposures in single energy mode	5-25 second exposures in single energy mode	5-25 second exposures in single energy mode
Max. X-ray tube voltage, kV	160	120	150
Focal spot size, µm	800	600	80
Resolution (Copper Wire), µm	80	60	40
Total Penetration (Al equivalent),mm	120	65	80
Total Penetration (Fe equivalent),mm	40	24	20

X-RAY IMAGE CONVERTER

Camera unit	Digital 1280×1024, 14 bit
Interchangeable converter, screening area, mm	190×250
	300×400 (standard)
	410×550
CONTROL UNIT	TFT LCD / LAPTOP
Screen dimensions	12” – 15”
Memory size (image number )	30000
Battery Life	2 Hours, or 60 X-ray images acquisitions
Output	60 pictures per hour
Operating Temperature	– 20°C ÷ +50 °C(-4°F ÷ +122°F)
Relative humidity	90% (35°C or 95°F)
Weight, kg* (*standard system configuration (NORKA 150))	less than 29 kg

XCAT Bomb Detector

The XCAT is intended for presumptive testing. Sampling cards are dedicated to detecting either individual analytes or groups of related analytes.

XCAT Applications

Among the intended users are: law enforcement, the military, federal agencies (FBI, CIA, DOI, DEA, DOS), border control, forensics experts, commercial security, fire departments, special events screening, home & business (parental, insurance).

The XCAT uses detection cards with specially formulated optical detection inks and software to identify characteristics unique to each individual or group of chemically related analytes.

Each analyte or group of analytes is detected with a dedicated card.

The unit uniquely identifies and analyzes each card (eg. Cocaine or GSR) and returns a red or green light signal to the user simply indicating “detection” or “no detection”.

Bomb Detection Kits

Shelf Life	12 months1
Operating Temperature Range	2ºC to 50ºC (35ºF to 122ºF)
Operating Humidity Range	10% to 95% RH
Sensitivity	Trace Level (can also detect bulk levels)
Explosives Detected	Nitroaromatics, e.g. TNT, DNT, Tetryl
	Nitramines/Nitrate Esters e.g. RDX, HMX, PETN, EGDN, NG
	Inorganic Nitrates e.g. urea nitrate, ammonium nitrate, black powder
	Chlorate/Bromates e.g. potassium chlorate, potassium bromate
	Peroxides e.g. TATP, HMTD
	Acids e.g. nitric acid, sulfuric acid, citric acid
	Bases e.g. potassium hydroxide, sodium hydroxide
Time for Color Change	Less than 3 minutes
Kit Size	131 mm x 92 mm x 17 mm (5-1/4” X 3-3/4” X 3/4”)

Hand-Held Explosive Detection Kits

Shelf Life	12 months1
Operating Temperature Range	2ºC to 50ºC (35ºF to 122ºF)
Operating Humidity Range	10% to 95% RH
Sensitivity	Trace Level (can also detect bulk levels)
Explosives Detected	Nitroaromatics, e.g. TNT, DNT, Tetryl
	Nitramines/Nitrate Esters e.g. RDX, HMX, PETN, EGDN, NG
	Inorganic Nitrates e.g. urea nitrate, ammonium nitrate, black powder
	Chlorate/Bromates e.g. potassium chlorate, potassium bromate
	Peroxides e.g. TATP, HMTD
	Acids e.g. nitric acid, sulfuric acid, citric acid
	Bases e.g. potassium hydroxide, sodium hydroxide
Time for Color Change	Less than 3 minutes
Kit Size	131 mm x 92 mm x 17 mm (5-1/4” X 3-3/4” X 3/4”)
